GALVANIZED STEEL WIRE STRAND 7/0.33MM

Raw Material :High carbon Steel
Surface:Galvanized
Construction :1X7
Dia: 1.0 mm
Length：24000 M
Package :Wooden reel
Origin :China

Specification
ASTM A475, ASTM A363, BS183:1972

Galvanized Steel Wire Stand ASTM-A475

Number of Wires/Dia.	Approx.Strand Dia.		Siemem Martin Grade	High Strength Grade	Extra-high Strength Grade	Approx.Weight

	Inch	mm	KN	KN	KN	kg/km
3/2.64	7/32	5.56	10.409	15.569	21.796	131
3/3.05	1/4	6.35	13.523	21.04	29.981	174
3/3.05	1/4	6.35	-	-	-	174
3/3.30	9/32	7.14	15.035	23.398	33.362	204
3/3.68	5/16	7.94	18.193	28.246	40.479	256
3/4.19	3/8	9.52	24.732	37.187	52.489	328
7/1.04	1/8	3.18	4.048	5.916	8.18	49
7/1.32	5/32	3.97	6.539	9.519	13.078	76
7/1.57	3/16	4.76	8.452	12.677	17.748	108
7/1.65	3/16	4.76	-	-	-	118
7/1.83	3/16	5.56	11.387	17.126	24.02	145
7/2.03	7/32	6.35	14.012	21.129	29.581	181
7/2.36	1/4	7.14	18.905	28.469	39.812	243
7/2.64	9/32	7.94	23.798	35.586	49.82	305
7/2.77	5/16	7.94	-	-	-	335
7/3.05	3/8	9.52	30.915	48.04	68.503	407

Galvanized Steel Wire Stand

Galvanized Steel Wire Strand is a high-strength, corrosion-resistant structural material composed of multiple steel wires twisted together and hot-dip galvanized or electro-galvanized for surface protection. It is widely used in construction, bridge engineering, power transmission, and other fields due to its excellent mechanical properties and durability. Below are its key technical parameters:

- Superior Strength and Durability:
Boasting a 1×7 1X19 configuration, this intricate design encompasses seven wires expertly twisted around a central core, delivering extraordinary tensile strength and deformation resistance. Such robust construction guarantees top-tier performance under both high-load and dynamic conditions.

- Galvanized Coating:
steel strand is enveloped in a premium galvanized zinc layer, providing extraordinary rust and corrosion resistance. This superior coating ensures suitability for harsh environments and significantly extends the strand's longevity.

- High Flexibility:
The sophisticated 1×7 design endows the strand with exceptional flexibility, allowing it to adapt seamlessly to various shapes and scenarios without compromising its structural soundness. This adaptability is especially advantageous in applications requiring maneuverability around obstacles or curves.

- Precision Engineering:
Crafted to the highest standards, 1X19 1×7 galvanized steel strand features uniform diameter and mechanical properties. Each strand is subjected to stringent quality control, ensuring compliance with industry specifications and exceptional performance.

- Versatile Applications:
Perfect for a multitude of applications, including but not limited to:
- Suspension and support cables for construction and infrastructure endeavors.
- Lifting and rigging operations across diverse industrial domains.
- Enhancing concrete and other construction materials with reinforcement.
- Agricultural and forestry uses where strength and dependability are critical.

1) Loading port: Nantong,China/SHANGHAI CHINA

2) Delivery term: FOB, CFR, CIF

3) Delivery lead time: 30 days after received deposit.

4) Payment term:30% by T/T as deposit., balance will be paid by T/T,

5) Quality assurance: Mill Test Certificate is supplied with shipment, third Party Inspection is acceptable.
